Share UAV PSDK 102S V3

Increase the speed of your drone surveys with the Share UAV PSDK 102S V3 - a 5-lens 125MP oblique camera.

Enhanced Image Quality Compatible with the DJI M300 RTK Series, this payload has five 25.16MP sensors, and the camera parameters can be adjusted to adapt to different weather and light.

No Extra Set-Up The PSDK 102 is instantly recognised as a payload, so operators do not need to do any additional set-up and launch their missions much faster.

Survey Support Access advice and support from our in-house survey team to help you integrate this Share UAV camera into your workflows.

Versatile Payload: The PSDK 102S V3 can adapt to many different scenarios and is compatible with any drone that can support its weight, including the DJI M350/ M300 and any payload-friendly

No Extra Set-Up: The PSDK 102 is instantly recognised as a payload, so operators do not need to do any additional set-up and launch their missions much faster.

Streamlined Data Processing: For no additional cost, operators can access the Share UAV Data Manager platform to merge all the camera data into one file. This process combines the many pictures each lens took and automatically merges them into a succinct series of images.

Use Any Mapping Software: Share UAV's data is compatible with any mapping software, such as DJI Terra, DJI Modify, Pix4D and Drone2Map. You can use whichever suits you best.

Four Oblique Camera Settings: The PSDK 102S V3 features four oblique camera settings, enhancing its versatility and adaptability for various tasks, from construction surveying to urban mapping.

Real 3D Modeling: Convert your images and videos into detailed 3D models. It's comparable to the DJI Mavic 3 Enterprise but faster.

Macro photography: Magnify the subject to life-size or bigger in exceptional detail, making reading the letters on signs possible.

2D Orthophotoquad: In this mode, you can merge the images you capture with a map of the area, enhancing your accuracy and providing you with a better visual of the area.

Smart City Modelling: Create interactive 3D models of the surveying area you can manipulate and zoom in on to see as much detail as possible.

Useful for Industries: Use the PSDK 102S V3 across various industries for your surveying and mapping operations across varies industries such as Public Safety, Oil and Gas and many more.

Maximised Battery Life with Lightweight Design: This lightweight construction extends flight times and boosts workload capacity, delivering peak performance without compromising power efficiency.

Frequent Surveying: The PSDK 102S V3 is tailored for regular survey operators, like those at ports and construction sites, making it perfect for weekly mapping.

Extend your fieldwork time: High sensitivity and low noise algorithms boost your daily operations by 3 hours. Adjust shutter speed, ISO, white balance, and colour mode to match your operating conditions, ensuring optimal performance seamlessly.

Multi-Use Camera: This versatile camera, with adjustable parameters and independent vertical lenses, combines SHARE's advanced optics for 2D/3D image capture and macro-photogrammetry, offering a cost-effective solution.

What's Included

What's in the Share UAV PSDK 102S V3 Box

Aerial Oblique Camera x 1

Storage Box x 1

Data Cable x 1

Gimbal Cover x 1

Data Storage Module x 1

Data Reading Module x 1

Cleaning Cloth x 2

User Manual x 1

Specification

Weight 1041g

Dimensions193 x 172 x 180mm

Additional Features

Supported Aircraft Compatible with DJI M350 RTK and various rotary and fixed-wing drones from different manufacturers

Camera Interface DJI Skyport Interface & Universal Aviation Plug Interface

Effective PixelsOver 25 million pixels single lens; totalling exceeding 125 million pixels

Sensor Specifications

Size: 23.1 x 15.4mm Pixel Size: 3.76umLens Focal Length Oblique: 35mm Nadir: 25mm

Storage Capacity 1280GB

Parameter Adjustment Features adjustable ISO, white balance, colour mode, and shutter speed settings; Bluetooth parameter adjustment capability

Data Speed Up to 600MB/s

GCP-Free Precision: Share UAV's Time Sync 2.0 technology ensures microsecond synchronization between camera, gimbal, flight control, and RTK, eliminating the need for Ground Control Points (GCPs) while enhancing accuracy.

Flight Route Editor: Use 3D models for visual flight route editing and preview simulated imaging results.

Enhanced Real-Time Position Tracking: The PSDK 102S V3's software empowers seamless data inscription onto photos, intelligent task management, and optimised copy speed,
